It is suitable for dry particle size between 0.074-5mm, also can process the particles whose moisture content is less than 70%.
The maximum feeding particle size is no more than 10mm.
The inclination angel of our linear vibrating screen generally is 0°~15°, it can’t be more than 25° even if there are some special materials need to increase the inclination angle.
1-6 layers can screen 7 kinds of specifications, and the screened particle size is uniform.
The layers commonly will be recommended not to exceed 5 layers, because the excitation force can’t transmit the force well if the layers exceed 5 layers.
1. Just leave us your WhatsApp or email, we send the latest price list to you.
2. Whenever, 7X24 hours online service is waiting for you.
3. Give us one chance, we will not let you down.
| Model | Effective screening area | Granularity size | Deck | Power(kw) | Speed(r/min) | Amplitude(mm) |
| ZSQ-520 | 500*2000 | 0.074-60 | 1-4 | 2*0.75 | 960 | 4-8 |
| ZSQ-840 | 800*4000 | 0.074-60 | 1-4 | 2*1.5 | 960 | 4-8 |
| ZSQ-1030 | 1000*3000 | 0.074-60 | 1-4 | 2*1.9 | 960 | 4-8 |
| ZSQ-1255 | 1200*5500 | 0.074-60 | 1-4 | 2*2.2 | 960 | 4-8 |
| ZSQ-1650 | 1600*5000 | 0.074-60 | 1-4 | 2*3.0 | 960 | 4-8 |
